SPECIAL PRICE new DP2 Subsea Vessel
We can now offer a brand new (2019 blt) DP2 Subsea Support Vessel for re-sale at the amazing low price of USD 21 million! Another sister available at $27 million. Building cost a are above $40 million!
Principal Dimension: Length overall 85.000 m Breadth moulded 22.000 m Depth moulded 8.000 m Draft moulded 6.300 m
Complement 11 x One(1)-Man Cabins 11 men
11 x Two(2)-Man Cabins 22 men 32 x Four(4)-Man Cabins 128 men Total 161 men 1 x Hospital 2 men
Tankage Fuel oil 1150 m3 Fresh water 740 m3 Drill water 1750 m3 Water ballast 280 m3 Mud 410 m3 Heeling 440 m3 Dry bulk cement (4 x 2000 ft3) 226 m3
Performance Deck loading 7.5 Tonnes/m2 Deck cargo capacity 800 Tonnes Clear deck area 730 m2 Moon Pool 8.0 m x 8.0 m Trial speed abt.12.5 knots
Deck Machinery 4-point Mooring Winches 4 x 40 tonnes @ 10m/min Tugger Winches 2 x 10 tonnes @ 15m/min Capstan 2 x 10 tonnes @ 15m/min Main Crane 100 tonnes SWL @ 10m Service Crane 3 tonnes SWL @ 14m
Fifi 1 equipment
Machinery Main engine 2 x 3000 HP YANMAR Propulsion system 2 x Azimuth thruster Generating set 3 x 800KW Diesel driven 2 x 1500KW shaft Alternator Bow thrusters 2 x 12T controllable pitch
CONTACT US FOR OUTLINE SPECS AND GA PLAN FOR YOUR REFERENCE. THE VESSEL IS READY FOR PROMPT DELIVERY EX QUALITY YARD IN CHINA.
Any use, disclosure, forward, printing or copying of this post without expressed permission is strictly prohibited. All particulars are believed to be correct but not guaranteed. All offers are made subject to prior sale, changes in specifications or price and to withdrawal from sales list without notice. Copyright © 2019 Wissmann & Associates LLC, All rights reserved.
